Measuring range | Smallest measuring range: 0…40 mbar / 400 mmH2O |
| Largest measuring range: 0…60 bar / 600 mH2O |
Analog output | 4…20 mA, 2-wires |
| 4…20 mA, 2-wires, II 1G Ex ia IIC T4 Ga |
| 0…10 V, 3-wires |
Power supply | 20 mA output: 9…30 V DC |
| 20 mA output ATEX: 12…30 V DC |
| 10 V output: 15…30 V DC |
Accuracy | ≤ ± 0,2 % FS @ 25 °C |
| ≤ ± 0,5 % FS @ 25°C ≤ 60 mbar |
Long term stability | ≤ ± 0,2 % FS / Year |
Response time | 200 ms - others on request |
Switch-on time | < 1 s |
Temperature coefficient | Zero: ≤ ± 0,02 % FS / Kelvin |
| Span: ≤ ± 0,02 % FS / Kelvin |
Medium temperature | -25…80 °C |
| -20…70 °C with EX ia IIC T4 |
Surrounding temperature | -25…80 °C |
| -20…70 °C with EX ia IIC T4 |
Storage temperature | -40…85 °C |
Short-circuit resistance | Permanent |
Reverse polarity protection | Protection against reverse polarity, but no function |
Electromagnetic compatibility | Interference emissions and immunity acc. to EN 61326 |
Vibration | 10 g RMS (25…2000 Hz acc. to DIN EN 60068-2-6) |
Shock | 500 g / 1 ms acc. to DIN EN 60068-2-27 |
Wetted materials | Housing: Stainless steel 1.4404 |
| Sensor: Ceramic Al2O3 |
| Sensor seal: FPM (Viton), NBR, EPDM, FFKM (Chemraz / Kalrez) |
Protection type | IP 68 |
Weight | Approx. 600 g with 5 m cable |
